Hot Runner Installation Guide

Synventive makes it easy for our customers to install and run their hot runner system. Our field service technicians are always ready to help, and you can also find detailed instructions in our online manuals.



Hot Runner Installation Guide (33 MB)



  • Nozzle Series Download
  • Threaded Nozzles
  • Sliding Nozzles
  • Single Valve Gate Nozzles
  • Single Thermal Nozzles
  • Manifolds for Threaded Nozzles
  • Manifolds for Sliding Nozzles

Download of Technical Data

Hot runner nozzles are the link to the cavity. They either directly gate into the part or into a sub runner which will lead into the cavity. There are four categories of hot runner nozzle styles available.
Select your nozzle type or manifold on the left side for additional information and download of
the technical data (pdf).

A New Hot Runner Catalog for the download of 3-D data will be online soon!



To get your individual 3-D data, try also the Synventive Hot Runner Configurator:

Go To The HOTRUNNER.SHOP

Threaded Nozzles Product Catalog Download







Thermal Gate
SW max.

Thermal Gate
SW max.

Thermal Gate
SW max.

Valve
Gate
SW max.

Valve
Gate
SW max.

Valve
Gate
SW max.





Nozzle Series

Cutout

Standard Flow
Bore
Ø


High Viscosity

Medium Viscosity

Low Viscosity

High Viscosity

Med Viscosity

Low Viscosity

Download Product Catalog

Associated Manifold Type

06E-03 20 6 30 70 120 10 45 80 06E-03 Product Catalog V37
09E-03 27 9 70 120 250 40 80 120 09E-03 Product Catalog V42, V45
09EX12-03 27-35 9 to 12 300 500 1000 70 150 350 09EX12-03 Product Catalog V50
12E-06 35 12 500 800 1500 100 250 500 12E-06 Product Catalog V50
12EX16-03 35-45 (52) 12 to 16 700 1000 2000 250 450 1000 12EX16-03 Product Catalog V55
16E-06 45 (52) 16 1000 1500 2500 500 800 1500 16E-06 Product Catalog V55
16EX22-03 45-62 16 to 22 1200 2000 3500 650 1000 1700 16EX22-03 Product Catalog V65
22E-06 55-62 22 1500 2500 5000 800 1200 2000 22E-06 Product Catalog V65
T16 46-68 16 1000 1500 4000 300 600 1500 T16 Product Catalog VH
T20 50-85 20 2000 3000 7500 300 600 1500 T20 Product Catalog VH
T24 57-89 24 5000 7500 15000 850 4450 7500 T24 Product Catalog VI

  *SW = Shotweight

Melt Viscosity Unit Material
High >150 Pa.s PC, PMMA, PEEK, PES, PSU, PEI, POM
Medium 60 to 150 Pa.s ABS, SAN, ASA, PBT, PET, POM (Copo), PA, PPE, PPO, PPS, PC/ABS, PC/PBT
Low <60 Pa.s PP, PE, PS, LCP, TPE

Sliding Nozzles Product Catalog Download

      Thermal Gate SW max. Thermal Gate SW max. Thermal Gate SW max. Valve Gate SW max. Valve Gate SW max. Valve Gate SW max.
Nozzle Series  Nozzle Style Flow Bore Ø  Range High Viscosity Medium Viscosity Low Viscosity High Viscosity Med Viscosity Low Viscosity Download Product Catalog Associated Manifold Type

SR16

APT

8-16

1000

1500

4000

300

600

1500

SR16 Product Catalog

VF

SR20

APT

8-20

3000

5000

10000

300

600

1500

SR20 Product Catalog

VF

SR24

APT

10-25

5000

7500

15000

850

4450

7500

SR24 Product Catalog

VF

  *SW = Shotweight

Melt Viscosity Unit Material
High >150 Pa.s PC, PMMA, PEEK, PES, PSU, PEI, POM
Medium 60 to 150 Pa.s ABS, SAN, ASA, PBT, PET, POM (Copo), PA, PPE, PPO, PPS, PC/ABS, PC/PBT
Low <60 Pa.s PP, PE, PS, LCP, TPE

Single Valve Gate Nozzles Product Catalog Download

      Thermal Gate SW* max. Thermal Gate SW* max. Thermal Gate SW* max. Valve Gate SW* max. Valve Gate SW* max. Valve Gate SW* max.
Nozzle Series  Nozzle Style  Flow Bore Ø  Range High Viscosity Medium Viscosity Low Viscosity High Viscosity Med Viscosity Low Viscosity Download Product Catalog
09SVP-03 API 9 - - - 10 50 80 09SVP-03 Product Catalog
12SVP-06 API 12 - - - 80 150 300 12SVP-06 Product Catalog
12SVH-06 API 12 - - - 80 150 300 12SVH-06 Product Catalog
16SVP-06 API 16 - - - 250 600 1500 16SVP-06 Product Catalog
16SVH-06 API 16 - - - 250 600 1500 16SVH-06 Product Catalog

  *SW = Shotweight

Melt Viscosity Unit Material
High >150 Pa.s PC, PMMA, PEEK, PES, PSU, PEI, POM
Medium 60 to 150 Pa.s ABS, SAN, ASA, PBT, PET, POM (Copo), PA, PPE, PPO, PPS, PC/ABS, PC/PBT
Low <60 Pa.s PP, PE, PS, LCP, TPE

Single Thermal Nozzles Download

      Thermal Gate
SW* max.
Thermal Gate
SW* max.
Thermal Gate
SW* max.
Valve Gate
SW* max.
Valve Gate
SW* max.
Valve Gate
SW* max.

Nozzle Series Nozzle Style Flow Bore
Ø
Range
High Viscosity Medium Viscosity Low Viscosity High Viscosity Med Viscosity Low Viscosity Download Product Catalog
06S-03 API 6 30 70 120 - - - 06S-03 Product Catalog
09S-03 API 9 70 120 250 - - - 09S-03 Product Catalog
12S-06 API 12 500 800 1500 - - - 12S-06 Product Catalog
16S-06 API 16 1000 1500 2000 - - - 16S-06 Product Catalog
22S-06 API 22 1500 2500 5000 - - - 22S-06 Product Catalog
SB5 APT 5 - 9 40 - - - SB5 Product Catalog
USB5 APT 5 - 9 40       USB5 Product Catalog
SB8 APT 8 300 500 1500 - - - SB8 Product Catalog
USB8 APT 8 300 500 1500       USB8 Product Catalog
SB13 APT 13 3000 5000 10000 - - - SB13 Product Catalog
SB15 APT 15 3000 5000 10000 - - - SB15  Product Catalog
SB24 APT 24 5000 7500 15000 - - - SB24 Product Catalog

  *SW = Shotweight

Melt Viscosity Unit Material
High >150 Pa.s PC, PMMA, PEEK, PES, PSU, PEI, POM
Medium 60 to 150 Pa.s ABS, SAN, ASA, PBT, PET, POM (Copo), PA, PPE, PPO, PPS, PC/ABS, PC/PBT
Low <60 Pa.s PP, PE, PS, LCP, TPE

Manifolds for Threaded Nozzles Download

Nozzle Series Nozzle Flow Bore Ø Range V37 V42 V45 V50 V55 V65 VH VI
    M = 37 M = 42 M = 45 M = 50 M = 55 M = 65 M = 80 M = 85
06E-03 4-6 06E-03-V37 Product Catalog
09E-03 9-11.5   09E-03-V42 Product Catalog 09E-03-V45 Product Catalog
12E-06 8-14       12E-06-V50 Product Catalog
12EX16-03 12~14 to 16-18         12EX16-03-V55 Product Catalog
16E-06 12-18         16E-06-V55 Product Catalog
16EX22-03 16~18 to 20-24           16EX22-03-V65 Product Catalog
22E-06 16-24           22E-06-V65 Product Catalog
T16 8-16             T16-VH80 Product Catalog
T20 10-20             T20-VH80 Product Catalog
T24 10-25               T24-VI85 Product Catalog



Manifolds for Sliding Nozzles Download

Nozzle Series  Nozzle Flow Bore Ø Range V37 V50 V65
    M = 37 M = 50 M = 65
SR16 8-16     VF65 Product Catalog
SR20 8-20     VF65 Product Catalog
SR24 10-25     VF65 Product Catalog



Support for Dynamic Feed Technology

Support for eGate Sync Technology

Support for Dynamic Feed Technology









will follow soon
